Important Attributes
| Attribute | Details |
|---|---|
| Product Name | RS232 + USB 4G LTE Modem |
| Model | SIM7600G-RU |
| Module | SIMCom SIM7600G |
| Network Technology | GSM / GPRS / EDGE / WCDMA / HSDPA / HSUPA / LTE |
| LTE Data Rate | Up to 150 Mbps DL / 50 Mbps UL |
| Interfaces | RS232 + USB |
| Positioning | GPS / GLONASS |
| GNSS Data Format | NMEA-0183 |
| SIM Card Slot | 1.8–3 V SIM card slot |
| Input Voltage | 7.5–24 V DC |
| Input Current | 1–2 A |
| Standby Current | 56 mA |
| Working Current | 100–140 mA |
| Operating Temperature | -30°C to +80°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | 85 × 54 × 25 mm |
| Weight | 100 g |
| Enclosure | Aluminum casing |
| GNSS Antenna | Passive / Active antenna |
Product Overview
The SIM7600G-RU 4G LTE Modem is an industrial cellular modem based on the SIMCom SIM7600G module, designed for reliable wireless data communication in industrial and remote applications.
Featuring RS232 and USB interfaces, the modem supports flexible integration with equipment requiring serial or USB connectivity. Its 7.5–24 V DC input range and -30°C to +80°C operating temperature range make it suitable for a variety of industrial environments.
The modem supports LTE, WCDMA, HSDPA, HSUPA, EDGE, GPRS and GSM technologies, together with GPS / GLONASS positioning and NMEA-0183 GNSS data output.
With an aluminum enclosure, compact dimensions of 85 × 54 × 25 mm, and a weight of approximately 100 g, the SIM7600G-RU provides a practical connectivity solution for industrial equipment and remote data communication systems.
Product Specifications
| Network & Wireless | |
|---|---|
| Cellular Module | SIMCom SIM7600G |
| LTE | LTE Cat 1, as stated in the source |
| LTE Downlink | Max. 150 Mbps |
| LTE Uplink | Max. 50 Mbps |
| HSDPA Downlink | Max. 14.40 Mbps |
| HSUPA Uplink | Max. 5.76 Mbps |
| WCDMA Downlink | Max. 384 Kbps |
| WCDMA Uplink | Max. 384 Kbps |
| EDGE Downlink | Max. 236.8 Kbps |
| EDGE Uplink | Max. 118 Kbps |
| GPRS Downlink | Max. 85.6 Kbps |
| GPRS Uplink | Max. 42.8 Kbps |
| CSD | 2.4 / 4.8 / 9.6 / 14.4 Kbps |
| GPRS Coding Scheme | CS 1–4 |
| EDGE Coding Scheme | MCS 1–9 |
| Other Protocols | PAP, PPP, PBCCH, USSD, UMTS R99 |
| GPS / GNSS | |
|---|---|
| GNSS Data Format | NMEA-0183 |
| Tracking Sensitivity | GPS: -159 dBm; GLONASS: -158 dBm |
| Cold-Start Sensitivity | -148 dBm |
| Position Accuracy | 2.5 m (CEP50), open sky |
| Hot Start TTFF | Less than 1 second, open sky |
| Cold Start TTFF | Less than 35 seconds, open sky |
| Receiver Type | 16-channel, C/A Code |
| GPS L1 Frequency | 1575.42 ± 1.023 MHz |
| GLONASS Frequency | 1597.5–1605.8 MHz |
| BeiDou Frequency | 1559.05–1563.14 MHz |
| Update Rate | Default 1 Hz |
| GNSS Antenna | Passive / Active |
| GNSS Current Consumption | 100 mA, as stated in the source |
| Interfaces & Electrical | |
|---|---|
| Input Voltage | 7.5–24 V DC |
| Input Current | 1–2 A |
| Standby Current | 56 mA |
| Working Current | 100–140 mA |
| Operating Temperature | -30°C to +80°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | 85 × 54 × 25 mm |
| Weight | 100 g |
| Enclosure | Aluminum |
| GSM Antenna Connector | Supported |
| GPS Antenna Connector | Supported |
| Data Communication & SMS | |
|---|---|
| Serial / USB Interface | RS232 + USB |
| SMS | MO / MT / CB |
| Cell Broadcast | Supported |
| SMS Mode | Text / PDU |
| SIM Application Toolkit | Supported |
Applications
ATM & POS Connectivity
Telecom Site Monitoring
CCTV & Remote Surveillance
Water & Wastewater Monitoring
EV Charging Stations
